HDCVI Camera 720p

HDCVI Camera 720p is 1/3" CMOS sensor 720p high definition camera. High Definition Composite Video Interfac (HDCVI) is the technology offering the fast and easy upgrade to high definition under conventional cabling environment. HDCVI features over-coaxial-cable analog HD video transmission allowing reliable long-distance HD transmission as a down cost solution. It renders 720P HD video format by analog modulation while offering megapixel high video quality.

HDCVI can run long range and non-latent transmission without further relay devices. HDCVI shows a distinguished advantage as it can transmit 1500ft with low signal distortion rate. HDCVI is more reliable as it adopts P2P transmission. It features no latency for an outstanding real-time performance and it requires no compressoin and thus present in vivid images.

HAC-HFW1100R-VF

1Megapixel 720P Waterproof HDCVI Vari-focal IR-Bullet Camera

  • 1/2.9" 1Megapixel CMOS
  • 25/30fps@720P
  • High speed, long distance real-time transmission
  • Day/Night(ICR), AWB, AGC, BLC, 2D-DNR
  • 2.7~12mm vari-focal lens
  • Max. IR LEDs length 30m, Smart IR
  • IP66, DC12V
Download
DH-HAC-HFW1100R-VF.pdf
Adobe Acrobat document [349.5 KB]

HAC-HDBW1100R-VF
1Megapixel 720P Vandal Proof
HDCVI Vari-focal Dome Camera with IR

  • 1/2.9" 1Megapixel CMOS
  • 25/30fps@720P
  • High speed, long distance real-time transmission
  • Day/Night(ICR), AWB, AGC, BLC, 2D-DNR
  • 2.7~12mm vari-focal /lens
  • Max. IR LEDs length 20m, Smart IR
  • IP66, DC12V


Download
DH-HAC-HDBW1100R-VF.pdf
Adobe Acrobat document [317.8 KB]



HAC-HFW2100B

1.3Megapixel 720P Waterproof HDCVI Bullet camera with IR



  • 1/3” 1.3 Megapixel CMOS
  • 25/30/50/60fps@720P
  • Real-time high speed transmission up to 1500 feet
  • HD and standard definition switchable.
  • OSD Menu, control over coaxial cable
  • Day/Night(ICR), AWB, AGC, BLC, 3D-DNR
  • 6mm fixed lens (2.8, 3.6mm, 8mm optional)
  • IR LEDs Length up to 90 feet, Smart IR technology
  • IP66, DC12V





Download
DH-HAC-HFW2100B-HDCVI.pdf
Adobe Acrobat document [248.9 KB]

HAC-HFW2100D

1.3 Megapixel 720P Waterproof HDCVI Bullet camera with Long range IR

  • 1/3" 1.3 Megapixel CMOS
  • 25/30/50/60fps @720P
  • High speed, real-time transmission up to 1500 feet
  • HD and standard definition switchable
  • OSD manual contral over coaxial cable
  • Day / Night(ICR), AWB, AGC, BLC, 3D-DNR
  • 8mm fixed lens (3.6mm, 6mm, 12mm, 16mm optional)
  • IR LEDs length up to 150 feet, Smart IR technology
  • IP66, DC12V





Download
DH-HAC-HFW2100D-HDCVI.pdf
Adobe Acrobat document [223.3 KB]

HAC-HFW 2100S

1.3 Megapixel 720P Waterproof HDCVI Mini Bullet camera with IR



  • 1/3" 1.3Megapixel CMOS
  •  25/30/50/60fps@720P
  •  High speed, real-time transmission up to 1500 feet
  •  HD and standard definition switchable.
  •  OSD Menu, control over coaxial cable
  •  Day/Night(ICR), AWB, AGC, BLC, 3D-DNR,
  • 6mm fixed lens (2.8mm, 3.6mm, 8mm optional)
  •  Max. IR LEDs length 60 feet, Smart IR technology
  •  IP66,DC12V
Download
DH-HAC-HFW2100S-HDCVI.pdf
Adobe Acrobat document [194.9 KB]

HAC-HDW 2100S

1.3 Megapixel 720P Waterproof HDCVI Mini Dome camera with IR

  •  1/3" 1.3Megapixel CMOS
  •  25/30/50/60fps@720P
  •  High speed, real-time transmission up to 1500 feet
  •  HD and standard definition switchable.
  •  OSD Menu, control over coaxial cable
  •  Day/Night(ICR), AWB, AGC, BLC, 3D-DNR,
  •  6mm fixed lens (2.8mm, 3.6mm, 8mm optional)
  •  IR LEDs length 60 feet, Smart IR technology
  •  IP66,DC12V
Download
DH-HAC-HDW2100S-HDCVI.pdf
Adobe Acrobat document [227.0 KB]

HAC-HDW1100M
1Megapixel 720P Waterproof
HDCVI Mini Dome Camera with IR
  • 1/2.9" 1Megapixel CMOS
  • 25/30fps@720P
  • High speed, long distance real-time transmission
  • Day/Night(ICR), AWB, AGC, BLC
  • 3.6mm fixed lens (2.8mm, 6mm, 8mm optional)
  • Max. IR LEDs length 20m, Smart IR
  • IP66, DC12V


Download
DH-HAC-HDW1100M.pdf
Adobe Acrobat document [339.5 KB]

HAC-HDW1100S
1 Megapixel 720P HDCVI
Mini dome camera with IR

  • 1/2.9" 1Megapixel CMOS
  • 25/30fps@720P
  • High speed, real-time transmission up to 1500 feet
  • OSD Menu, control over coaxial cable
  • Day/Night (ICR), AWB, AGC, BLC
  • 3.6mm fixed lens (2.8mm, 3.6mm, 8mm optional)
  • Max. IR LEDs length 60 feet, Smart IR
  • DC12V


Download
DH-HAC-HDW1100S.pdf
Adobe Acrobat document [400.6 KB]

HAC-HFW1100S
1 Megapixel 720P Waterproof HDCVI
Bullet camera with IR

  • 1/2.9" 1Megapixel CMOS
  • 25/30fps@720P
  • High speed, real-time transmission up to 1500 feet
  • OSD Menu, control over coaxial cable
  • Day/Night (ICR), AWB, AGC, BLC
  • 6mm fixed lens (2.8mm, 3.6mm, 8mm optional)
  • Max. IR LEDs length 60 feet, Smart IR
  • IP66, DC12V
Download
HAC-HFW1100S.pdf
Adobe Acrobat document [301.5 KB]
